UBNT-LAP-120
Ubiquiti LAP-120 is a complete radio system designed for 5GHz band working at 802.11ac standard. The LiteBeam features a unique ball joint mount that provides adjustment flexibility along three axes for versatile mounting options. The device is equipped with integrated 25dBm radio module, 16dBi antenna and one Gigabit Ethernet port (10/100/1000Mbps). LAP-120 is designed to be a high performance and long range (up to 30km) device. It is powered by Passive PoE (PoE adapter included).
Technical Specification:
| LAP-120 | |
|---|---|
| Dimensions (Mount Not Included) | 452.3 x 78.7 x 54.4 mm (17.81 x 3.10 x 2.14″) |
| Weight (Mount Not Included) | 420 g (14.82 oz) |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| Mounting Kit | pole Mounting Kit (Included) |
| Memory | 64 MB |
| Max. Power Consumption | 7W |
| Antenna Gain | 16 dBi |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Supported Voltage Range | 20 – 26VDC |
| ESD/EMP Protection | ± 24kV Contact / Air |
| Shock and Vibrations | ETSI300-019-1.4 |
| Processor Specs | Atheros MIPS 74Kc, 533 MHz |
| RoHS Comoliance | Atheros MIPS 74Kc, 533 MHz |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 77 N @ 200 km/h (17.3 lbf @ 125 mph) |
| Operating Temperature | -40 to 70° C (-40 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
