Our first outdoor 5G device with built-in eSIM support, powerful directional antennas, and a cutting-edge Release 16 modem – ideal for rural, urban, and IoT deployments. With Gigabit Ethernet, PoE-in, and instant MikroTik Connectivity out of the box, it’s the smart, rugged choice for fast and flexible internet anywhere. IP66 certified.
| Product | ATL 5G R16 |
| Product code | ATLGM&RG520F-EU |
| Device type | Outdoor 5G CPE / router |
| Modem | RG520F-EU |
| CPU | Marvell 88F3720 |
| CPU cores | 2 |
| CPU frequency | 800 MHz |
| Architecture | ARM 64-bit |
| RAM | 512 MB DDR3L |
| Storage | 32 MB Flash |
| Operating system | RouterOS v7 |
| RouterOS license | Level 3 |
| Ethernet | 1 × 10/100/1000 Mbps Gigabit Ethernet |
| M.2 slots | 1 |
| SIM | 1 × Micro SIM |
| eSIM | Yes |
| Antenna gain | 16 dBi |
| MIMO | 4×4 DL / 2×2 UL |
| 5G SA maximum | 4.2 Gbps DL / 900 Mbps UL |
| 5G NSA maximum | 5.0 Gbps DL / 650 Mbps UL |
| LTE category | Cat 20 |
| LTE maximum | 2.0 Gbps DL / 200 Mbps UL |
| 3G category | R8 — 42.2 Mbps DL / 5.76 Mbps UL |
| 5G SA FDD bands | B1, B3, B5, B7, B8, B20, B28 |
| 5G SA TDD bands | B38, B40, B41, B75, B76, B77, B78 |
| 5G NSA FDD bands | B1, B3, B5, B7, B8, B20, B28 |
| 5G NSA TDD bands | B38, B40, B41, B75, B76, B77, B78 |
| LTE FDD bands | B1, B3, B5, B7, B8, B20, B28, B32 |
| LTE TDD bands | B38, B40, B41, B42, B43 |
| 3G bands | B1, B5, B8 |
| Power input | PoE-in, 12–56 V DC |
| PoE standard | 802.3af/at |
| Power adapter | 24 V / 0.8 A |
| Maximum power consumption | 10 W |
| Cooling | Passive |
| Operating temperature | −40°C to +70°C |
| IP rating | IP66 |
| MTBF | Approx. 200,000 hours @ 25°C |
| Certifications | CE, EAC, RoHS |
| TAC | 86945405 |
| Dimensions | 311 × 311 × 179 mm |
| Mounting | Outdoor pole mounting |
| Included | 24 V / 0.8 A power adapter, Gigabit PoE injector, hose clamps |
