Features
- 10/100/1000 MbPS
- All 4 pairs are protected by the reliable differential Gas Discharge Tube (GDT)
- Provide transient protection for the protected differential line pair to IEEE 802.3 af/at (Transmission) IEC 61000-4-5 (Lightning/Surge) 20KA( 8 / 2 0 ¼ s )
- PoE input voltage Vmax up to 60V
- PoE input current Imax up to 2A
- Shielded/Grounded RJ-45 Jacks
- Bi-directional clamping
- Removable board design for easy installation
- Impact and weather resistant enclosure withlocking hinged cover
- Mounting holes at the rear of the enclosure
- Cable grommet may be adjusted to cable size and are removable
- IEC61000-4-5 and CORE 1089 compliant
- RoHS compliant
Specifications
| Details |
|
| Clamping Voltage | Line-Ground: 60 Volts Line-Line: 60 Volts |
| Maximum Impulse Discharge Current ( 8 / 2 0 ¼ s ) | 20 KA |
| PoE Maximum Input Voltage Vmax | 60 V |
| PoE Maximum Input Current Imax | 2 A |
| Protection Modes | Line-Line, Line-Ground |
| Standard Connectors | Shielded RJ-45 Fema le * 2 |
| Enclosure Material | Polycarbonat e |
| Enclosure Color | Gray |
| Ground Lug | 12 AWG Max. |
| Operating Temperature | -40°C ( -40°F) to +80°C (+176°F) |
| Outside Dimens ions (W*L*H) | 78*103*49 mm |
| Weight | 110 g |
