The TwistPort™ Adaptor for Mimosa C5x makes the radio compatible with all TwistPort™ Antennas. TwistPort™ Adaptors are equipped with our original quick-locking waveguide port. With the C5x TwistPort™ adaptor, you can easily switch between H/V and dual slant polarization setup. Specifications TECHNICAL DATA
| Antenna Connection | TwistPort™ – Quick Locking Waveguide Port |
| Materials | Insert – Aluminium Alloy Adaptor – UV stabilized and weather resistant ABS plastic |
| Flame Rating | UL 94 HB |
| Temperature | -40°C to +60°C (-40°F to +140°F) |
| Wind Survival | 160 km/h |
| Weight | 0.17 kg / 0.3 lbs – single unit 0.20 kg / 0.4 lbs – single unit incl. package 19.5 kg / 43 lbs – carton (100 units) |
| Single Unit | Retail Box: 109 × 98 × 54 mm / 4.2 x 3.8 x 2.1 inch |
| 100 Units | Carton Box: 570 × 520 × 250 mm / 22.4 x 20.5 x 9.8 inch |
COMPATIBLE WIRELESS PLATFORMS
| RF elements® | any TwistPort™ Antenna* |
| Mimosa Networks | C5x |
PACKAGE CONTENTS TwistPort™ Adaptor
