Περιγραφή
- t
- Maximum coverage – four 5dBi antennas provide up to 500m2of wireless coverage
- Enhanced signal – high gain antennas dramatically increase wireless signal strength, size and stability
- 300Mbps wireless speed – ideal for HD streaming, online gaming, and large file downloads
- Easy installation – intuitive webpage guides you through the setup process in minutes
- *Range speci cations are based on performance test results. Real performance varies in accordance with applications and environmental conditions.
t
t
t
t
| Dimensions (W X D X H) | 167 x 118 x 33 mm |
| Interfaces | 4 10/100Mbps LAN ports 1 10/100Mbps WAN port |
| Button | Reset button |
| External Power Supply | 9VDC/0.6A |
| Antenna Type | 4 x 5dBi fixed omni directional antennas |
| Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Frequency | 2.4 – 2.4835GHz |
| Signal Rate | 11n: Up to 300Mbps (Dynamic) 11g: Up to 54Mbps (Dynamic) 11b: Up to 11Mbps (Dynamic) |
| Reception Sensitivity | 270M: -70dBm@10% PER 130M: -74dBm@10% PER 108M: -74dBm@10% PER 54M: -77dBm@10% PER 11M: -87dBm@8% PER 6M: -90dBm@10% PER 1M: -98dBm@8% PER |
| Certifications | CE, ROHS |
| Package Contents | 300Mbps Enhanced Wireless N Router MW325R Power adapter Quick installation guide Ethernet cable |
| Environment | Operating temperature: 0⁰C ~ 40⁰C (32⁰F ~ 104⁰F) Storage temperature: -40⁰C ~ 70⁰C (-40⁰F ~ 158⁰F) Operating humidity: 10% ~ 90%, non-condensing Storage humidity: 5% ~ 90%, non-condensing |
| Transmission Power | <20dBm |
| Wireless Security | WPA-PSK / WPA2-PSK |
| Wireless Functions | WDS bridge |
| WAN Type | Dynamic IP/Static IP/PPPoE |
| Management | Access control Local management Remote management |
| DHCP | Server |
| Port Forwarding | Virtual server, UPnP, DMZ |
| Dynamic DNS | Oray |
| Firewall Security | IP and MAC address binding |
| Protocols | IPv4 |
| Guest Network | 2.4GHz guest network |
