Technical Data:
| Manufacturer: | Interline |
| Model: | IP-G08-F2425-HV |
| Type of Antenna: | Directional Panel Antenna |
| Gain: | 8dBi |
| Impedance: | 50 Ohm |
| Frequency: | 2400 – 2500 MHz (IEEE 802.11 b/g/n) |
| VSWR: | max. 2.00:1 |
| Polarisation: | Horizontal or Vertical (Linear) |
| Beam width: | 57° Horizontal 60° Vertical |
| Front to back ratio: | min. 20dB |
| XPD (Cross Polarization Discrimination): | min. 8dB |
| Connector: | N female socket |
| Appliance: | In- and Outdoor |
| IP Rating: | IP64 |
| max. Windload: | 17.5N (@170km/h) |
| Ground: | DC-Ground |
| Dimensions: | 11.5cmcm x 11.5cm x 1.8cm |
| Weight: | 340g |
| Color: | White / Grey |
