UBNT-UAP-AC-LITE
UBNT-UAP-AC-LITE is a model of Ubiquiti Unifi AP that supports 802.11ac standard providing bandwidth up to 867Mbps on band 5GHz. The band 2.4GHz offers up to 300Mbps using the two integrated 2×2 MIMO antennas. UAP AC LITE can simultaneous operation in both bands (2.4 and 5 GHz), allows to connect clients to 2.4GHz with simultaneous 5GHz efficient uplink connection. The device has one Gigabit Ethernet port and supports Roaming.
Buying UBNT-UAP-AC-LITE-5 you get five UBNT-UAP-AC-LITE in one box without power supplies.
UniFi AP LITE – The most important features
- Free controller (UNIFI 3.0)
- Dual-band radio (2.4 and 5 GHz)
- Support for 5GHz 802.11ac
- Easy to mount on a wall or ceiling (mounting hardware included)
- Aesthetic appearance and LED Indicating device status
- Power over Ethernet (PoE)
| Mechanical | |
|---|---|
| Dimensions | 160 x 160 x 31.45 mm (6.30 x 6.30 x 1.24″) |
| Weight With Mounting Kits |
170 g (6.0 oz) 185 g (6.5 oz) |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| Buttons | Reset |
| Power Method | 802.3af/A PoE 24V Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter* |
| Power Save | Supported |
| Maximum Power Consumption | 6.5W |
| Max TX Power 2.4 GHz 5 GHz |
20 dBm 20 dBm |
| Antennas | (2) Dual-Band Antennas, 3 dBi Each |
| Wi-Fi Standards | 802.11 a/b/g/n/r/k/v/ac |
| Wireless Security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| BSSID | Up to 8 per Radio |
| Mounting | Wall/Ceiling (Kits Included) |
| Operating Temperature | -10 to 70° C (14 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| Advanced Traffic Management | |
| VLAN | 802.1Q |
| Advanced QoS | Per-User Rate Limiting |
| Guest Traffic Isolation | Supported |
| WMM | Voice, Video, Best Effort, and Background |
| Concurrent Clients | 250+ |
| Supported Data Rates (Mbps) | |
| 802.11ac | 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80) |
| 802.11n | 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b | 1, 2, 5.5, 11 Mbps |
