Ubiquiti TOUGHCablePRO
industrial-grade shielded ethernet cable. Cable Level 1 is a Category 5e Outdoor Carrier Class Shielded Cable. Protect your networks from the most brutal environments with Ubiquiti’s industrial-grade shielded Ethernet cable, TOUGHCablePRO. Increase Performance Dramatically improve your Ethernet link states, speeds, and overall performance with Ubiquiti TOUGHCablePRO.
Extreme
Weatherproof TOUGHCablePRO have been built to perform even in the harshest weather and environments.
ESD Damage Protection Protect
your networks from devastating electrostatic discharge (ESD) attacks.
Extended Cable
Support TOUGHCablePRO have been developed to have increased power handling performance
Important features:
- 24 AWG copper conductor pairs
- 26 AWG integrated ESD drain wire to prevent ESD attacks & damage
- PE outdoor-rated weatherproof jacket
- Multi-layered shielding
- Available in 1000 ft (304.8 m) length
Technical Specification:
| Mechanical | |
|---|---|
| Box Dimensions | 330 x 330 x 340 mm |
| Box Weight | 12 kg |
| Cable Length | 305 m (1000 ft) |
| Cable Color | Black |
| Cable Type | CAT5e, Shielded |
| Ethernet Support | Up to 1 Gbps |
| Conductor Wire Gauge | 24 AWG |
| Conductor | Solid Bare Copper |
| Conductor Diameter | 0.500 ± 0.005 mm |
| Insulation Type | Solid Polyethylene |
| Insulation Thickness | Avg. 0.26 mm Min. 0.25 mm |
| Insulation Diameter | 1.04 ± 0.03 mm |
| Separation (Polyester Wrapping) | Thick: 0.025 mm, Extent: 20 mm |
| Anti-Crosstalk Divider | None |
| Cable Shield (Aluminum Foil) | Thick: 0.060 mm, Extent: 18 mm |
| ESD Drain Wire | 0.4 CCS |
| Rip Cord | Yes |
| Jacket Material | Polyethylene |
| Jacket Thickness | Avg. 0.50 mm Min. 0.46 mm |
| Jacket Outer Diameter | 6.0 ± 0.30 mm |
| Jacket Color | Black |
| Storage Temperature | -30 to 75° C (-22 to 167° F) |
| Installation Temperature | -20 to 60° C (-4 to 140° F) |
| Operation Temperature | -40 to 80° C (-40 to 176° F) |
| Standards | ANSI/TIA-568-C.2 (2009) ISO/IEC 11801 (Edition 2.2) |
