The MonsterDish™ is a 5 GHz, 37 dBi antenna that is ideal for Point-to-Point (PtP) links of 100+ km. Its all-aluminum design enhances reliability and features a precision alignment mount. The MonsterDish is compatible with a 5 GHz Rocket® or airFiber® radio. It can be shipped using standard DHL, FedEx, or UPS shipping due to its compact size when disassembled for transport.
Technical Specifications :
| Mechanical | |
|---|---|
| Dimensions | Ø1600 x 820 mm (Ø62.9 x 32.2″) |
| Weight | Without Mount: 19 kg (41.9 lb) With Mount: 40.9 kg (90.2 lb) |
| Enclosure Material | Aluminum/UV Stabilized Polycarbonate |
| Mount Material | Aluminum/UV Stabilized Polycarbonate |
| Mount Material | Aluminum Sheet Metal/Steel Hardware with Geomet Coating |
| Mounting | Pole Mount (Kits Included |
| Caution! | Pole or structure that the antenna mounts to should ensure support of the 40.9 kg (90.2 lb) weight and windload. |
| RF | |
| Frequency Range | 4.9 to 5.8 GHz |
| Antenna Gain 4.9 GHz 5.2-5.8 Ghz |
34 dBi 35-37 dBi |
| HPOL Beamwidth | 2.5° (3 dB) |
| VPOL Beamwidth | 2.5° (3 dB) |
| Elevation Beamwidth | 2.5° (3 dB) |
| Electrical Downtilt | 0° |
| Maximum VSWR | 1.7:1 |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 6385 N @ 200 km/h (1435 lbf @ 125 mph) |
| Polarization | Dual-Linear (Slant 45 with Adaptor) |
