Περιγραφή
AP-5AC-90-HD
Ubiquiti introduces an innovative sector antenna for your Point-to-MultiPoint (PtMP) applications, the airPrism® 5 GHz 3×30° HD Sector Antenna. The airPrism antenna features significant advances in noise isolation and beam performance to complement the Rocket®5ac Prism™ radios (not included) for co-location deployments.
Features:
- Powerful Performance for High-Density Areas
- 3 x 30° Beamwidth Coverage in a MultiPoint Network
- Efficient Footprint for Reduced Tower Costs
AP-5AC-90-HD is the airPrism® 5GHz 3×30° HD Sector Antenna – an innovative sector antenna for Point-to-MultiPoint (PtMP) applications.
The airPrism antenna features significant advances in noise isolation and beam performance to complement the Rocket®5ac Prism™ radios (not included) for co-location deployments.
Three Rocket5ac Prism radios mounted on a single airPrism antenna maximizes throughput in an efficient tower footprint, minimizing installation and tower costs.
Highly resistant to noise interference, the airPrism antenna provides superior beam performance in high-density areas for high-capacity, multipoint networks.
The airPrism antenna and Rocket5ac Prism radios have been designed to seamlessly work together. Every airPrism antenna has three built-in Rocket radio mounts, so installation requires no special tools. Snap the three Rocket5ac Prism radios securely into place and mount the antenna for your PtMP link.
The three Rocket5ac Prism radios are installed at the top, middle, and bottom of the airPrism antenna. Each radio independently transmits and receives within its corresponding 30° beamwidth.
Technical Specifications:
| AP-5AC-90-HD | |
|---|---|
| Dimensions (Mount Included) | 322.6 x 201.5 x 1300 mm (12.7 x 7.93 x 51.18″) |
| Weight (Mount Included) |
13.1 kg (28.9 lb) |
| Frequency Range | 5.15 – 5.85 GHz |
| Gain | 22 dBi |
| HPOL Beamwidth | 3 x 30° (6 dB) |
| VPOL Beamwidth | 3 x 30° (6 dB) |
| Elevation Beamwidth | 8° |
| Electrical Downtilt | 2° |
| Polarization | Dual-Linear |
| Max. VSWR | 1.75:1 |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 534 N @ 200 km/h (120 lbf @ 125 mph) |
| Interfaces | (6) RP-SMA Connectors (Weatherproof) |
| Compatible Radio | Rocket5ac Prism |
| Mounting | Pole Mount (Kit Included) |
| ETSI Specification | EN 302 326 DN2 |
| Certifications | CE, FCC, IC |
