Περιγραφή
TL-WA901N is designed to establish or expand a scalable high-speed wireless N network or to connect an Ethernet-enabled device such as a game console, digital media adapter, printer, or network-attached storage device to a wireless network. The AP supports a host of different functions that makes your wireless networking experience more flexible than ever before. Now, you can enjoy a better Internet experience when downloading, gaming, video streaming or any other application that you may wish to use. Features
- t
- 450Mbps wireless transmission rate brings smooth wireless N experience
- Supports multiple operating modes: Access Point, Range Extender, Multi-SSID and Client modes
- Easily setup a WPA-PSK/WPA2-PSK encrypted secure connection at a push of the WPS button
- Up to 30 meters (100 feet) of flexible deployment with included Power over Ethernet Injector
t
t
t
TL-WA901N Specifications
| HARDWARE FEATURES | |
|---|---|
| Interface | 1× 10/100M Ethernet Port(RJ45) Support Passive PoE |
| Button | Power On/Off Button, Reset Button, WPS Button |
| External Power Supply | 9VDC / 0.9A |
| Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Dimensions ( W x D x H ) | 7.7 × 5.3 × 1.4 in (195 × 134 × 36 mm ) |
| Antenna Type | 3 Fixed Omni-Directional Antennas |
| WIRELESS FEATURES | |
|---|---|
| Frequency | 2.4 GHz |
| Signal Rate | 450 Mbps at 2.4 GHz |
| Reception Sensitivity | 11g 54M: -76dBm 11n 20Mbps: -73dBm 11n 40Mbps: -70dBm |
| Transmit Power | < 30dBm |
| Wireless Modes | Access Point, Range Extender, Client, Multi-SSID |
| Wireless Functions | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions |
| DHCP | Server, DHCP Client List |
| Quality of Service | WMM |
| Management | SNMP |
| Advanced Functions | Up to 30 meters PoE is supported |
| OTHERS | |
|---|---|
| Certification | FCC, RoHS |
| Package Contents | Wireless N Access Point TL-WA901N Power Adapter Passive PoE Power Injector RJ45 Ethernet Cable Quick Installation Guide |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Protocol Support | IPv4, IPv6 |
