General Features
- t
- Innovative energy-efficient technology saves power up to 15%
- Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
- Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
- 32Gbps Switching Capacity
- 10K Jumbo frame improves performance of large data transfers
- Auto-MDI/MDIX eliminates the need for crossover cables
- Supports MAC address auto-learning and auto-aging
- Store and forward Switching scheme
- Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps and 1000Mbps hardware.
- Plug and Play design simplifies installation
t
t
t
t
t
t
t
t
t
Specifications
| Hardware Features | |
|---|---|
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x |
| Interface | 16 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) |
| Network Media | 10Base-T: UTP category 3, 4, 5 cable (maximum 328.1feet) EIA/TIA-568 100Ù STP (maximum 328.1feet) 100Base-Tx: UTP category 5, 5e cable (maximum 328.1feet) EIA/TIA-568 100Ù STP (maximum 328.1feet) 1000Base-T: UTP category 5, 5e cable (maximum 328.1feet) |
| Fan Quantity | Fanless |
| Power Supply | 100-240VAC, 50/60Hz |
| Dimensions ( W x D x H ) | 11.6*7.1*1.7 in. (294*180*44 mm) |
| Power Consumption | Maximum: 13.3W (220V/50Hz) |
| Performance | |
|---|---|
| Switching Capacity | 32Gbps |
| MAC Address Table | 8K |
| Packet Forwarding Rate | 23.8Mpps |
| Jumbo Frame | 10KB |
| Green Technology | Innovative energy-efficient technology saves power up to 15% |
| Transfer Method | Store-and-Forward |
| Others | |
|---|---|
| Certification | FCC, CE, RoHs |
| Package Contents | 16-Port Gigabit Desktop/Rackmount Switch Power Cord Installation Guide Rackmount Kits Rubber Feet |
| System Requirements | Microsoft® Windows® XP, Vista™, Windows 7 or Windows 8, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing |
