RouterBoard RBSXTSQ5HPND
The SXTsq 5 is a compact and lightweight outdoor wireless device with an integrated antenna, perfect for point-to-point links or as a CPE unit. It is compact, weatherproof and easy to mount. The SXTsq 5 retains a 16 dBi antenna like the SXT 5, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced – the SXTsq is two times thinner. Higher TX power allows to reach longer distances than SXTsq Lite 5.
Technical Specifications:
| CPU | AR9344, 600 MHz, 1 core |
| RAM | 64 MB |
| Storage | 16 MB Flash |
| Ethernet port | 1x 10/100mbps |
| Wireless bands | 5GHz |
| Operating frequency | Wersja miÄ™dzynarodowa: 5150 – 5875 MHz USA: 5170 – 5250 MHz, 5725 – 5835 MHz |
| Protocols | 802.11a/n |
| Chains | Dual-chain |
| Antenna gain | 16 dBi |
| Antenna beam width | 23° |
| Wireless chip model | AR9344 |
| PoE in | Tak |
| Obsługiwane napięcie wejściowe | 10-28 V, pasywne PoE |
| Dimensions | 129x129x34 mm; package: 255x180x45 mm |
| Weight | Unit: 295 g, package: 492 g |
| Operating temperature | -40 to 70° C |
| License level | 4, RouterOS |
| Max Power consumption | 7W |
