| Specifications | |
| Network Port | 3x 10/100Mbps PoE RJ45 port (port 2～port 4) 802.3af/at 1x 10/100Mbps PoE RJ45 port (port 1) 802.3af/at/bt 2x 10/100Mbps Non-POE RJ45 port (port 5, 6) |
| Transfer Rate | 100Mbps full Duplex, 10 or 100Mbps Half Duplex Network interface: 10BASE-T or 100BASE-TX Ethernet RJ-45 |
| Performance | bandwidth: 1.2Gbps (no block) network delay (100 to 100Mbps): maximum 20 μs (using 64 byte packet) MAC address capacity: 1K Frames filter and transfer rate: 10M port maximum 14,800pps 100M port maximum 148,800pps |
| Network protocol and standard | IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3x Flow Control IEEE 802.3af/at Power over Ethernet |
| POE pin | 1/2(+), 3/6(-) |
| LEDs indicator | Power – PWR Link/PoE 250M/VLAN |
| Power | Total power: 65W (All PoE port, port 1~port 4) single port max. 30W, (port 1 up to 60W) Input power: 65W; 52V @ 1.25A DC output power |
| Dimensions(LxWxH) | 138mm x 81mm x 22mm |
| Environment | Operating Temperature: 0°~40°C Storage Temperature: -30℃~70℃ Working Humidity: 10%~90% (Non-condensing) Storage Temperature: 5%~90% (Non-condensing) |
| EMC | CE Class B FCC Part 15, Class B VCCI Class B, RoHS |
| Package contents | Device Power adapter 52V/2.5A Power cord |
