APC Smart-UPS RT 1000VA, 230V, rackmount, 2U, 6x IEC 60320 & 2x IEC Jumpers outlets, w/network card

APC Smart-UPS RT 1000VA, 230V, rackmount, 2U, 6x IEC 60320 & 2x IEC Jumpers outlets, w/network card

2.000,00 €

Κωδικός προϊόντος: SURT1000RMXLI-NC Κατηγορία:

Περιγραφή

APC Smart-UPS RT 1000VA, 230V, rackmount, 2U, 6x IEC 60320 & 2x IEC Jumpers outlets, w/network card
High density, double-conversion on-line power protection with scalable runtime.
Includes: CD with software, Rack mounting support rails, Smart UPS signalling RS-232 cable, User manual
Technical Specifications:

Output

Max Configurable Power (Watts)

700 Watts / 1.0kVA

Output Voltage Note

Configurable for 220 : 230 or 240 nominal output voltage

Output Voltage Distortion

Less than 3 %

Output Frequency (sync to mains)

50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Hz Sync to mains

Other Output Voltages

220 V, 240 V

Load Crest Factor

3 : 1

Topology

Double conversion online

Waveform type

Sine wave

Bypass

Built-in bypass

Input

Input frequency

50/60 Hz +/- 5 Hz Auto-sensing

Input voltage range for main operations

160 – 280V

Other Input Voltages

220 V, 240 V

Batteries & Runtime

Battery type

Lead-acid battery

Typical recharge time

3hour(s)

Replacement Battery

RBC31

Expected Battery Life (years)

3 – 5

RBC Quantity

1

Battery Charge Power (Watts)

109 Watts

Extendable Run Time

1

Communications & Management

Interface Port(s)

DB-9 RS-232, SmartSlot

Control panel

LED status display with load and battery bar-graphs and on line : on battery : replace battery : overload and bypass indicators

Audible Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Emergency Power Off (EPO)

Optional

Available SmartSlot™ Interface Quantity

1

Surge Protection and Filtering

Surge energy rating

420Joules

Filtering

Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

Maximum Height

85MM, 8.5CM

Maximum Width

432MM, 43.2CM

Maximum Depth

483MM, 48.3CM

Net Weight

23.0KG

Shipping weight

27.8KG

Shipping Height

286MM, 28.6CM

Shipping Width

630MM, 63.0CM

Shipping Depth

594MM, 59.4CM

Color

Black

Master Carton Units

1.0

Units per Pallet

4.0

Environmental

Operating Temperature

0 – 40 °C

Operating Relative Humidity

0 – 95 (Non-condensing) %

Operating Elevation

0 – 3048meters

Storage Temperature

-20 – 50 °C

Storage Relative Humidity

0 – 95 (Non-condensing) %

Storage Elevation

0 – 15240meters

Audible noise at 1 meter from surface of unit

50.0dBA

Online thermal dissipation

324.0BTU/hr

Protection Class

IP20

Conformance

Approvals

C-Tick, CE, EN 50091-1, EN 50091-2, EN 60950, EN 61000-3-2, GOST, VDE

Standard warranty

2 years repair or replace

Sustainable Offer Status

RoHS

Compliant
